Hydro Pneumatic Cylinders

Name: Hydro Pneumatic Cylinders
Brand: NATIONAL PNEUMATIC SYSTEMS
Price: 35000 INR
Availability: InStock

Price 35000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Hydro Pneumatic Cylinders Specification

Connectivity Type
Port connections: BSP/NPT

Mounting Type
Flange / Foot / Trunnion / Custom

Efficiency
High repeatability, low maintenance

Flow Rate
As per application

Sealing Type
PU and NBR Seals for Leak-proof Performance

Operating Pressure
Hydraulic: Up to 200 Bar, Pneumatic: 5-7 Bar

Application
Pressing, Clamping, Riveting, Punching, Forming

Features
Compact design, Energy efficient, High output force, Low air consumption

Accessories
Mounting brackets, Sensors, Air-hydraulic boosters

Temperature Range
-10°C to +80°C

Usage
Industrial

Body Material
Aluminium / Mild Steel with Hard Chrome Plated Rod

Size
Customized

Type
Hydro Pneumatic Cylinder

Structure
Double acting

Force
Up to 25 Tons

Speed
Up to 500 mm/sec

Voltage
Not required (Pneumatic Operation)

Color
Multicolor

Corrosion Resistance
Yes, with SS options and coated body

Port Size
1/8'' to 1'' BSP/NPT

Control Type
Manual / Solenoid Valve Controlled

Bore Size
32 mm to 400 mm (based on model)

Stroke Length
25 mm to 1000 mm (customizable)

Surface Finish
Chrome Plated Rod, Powder Coated/ Painted Body

Maintenance
Low Maintenance Design

Cushioning
Adjustable End Cushioning Available

Minimum Order Quantity
1 Unit

Hydro Pneumatic Cylinders Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
40 Pieces Per Month

Delivery Time
1 Week

Packaging Details
Wooden Boxes

Main Domestic Market
All India

About Hydro Pneumatic Cylinders

Hydro Pneumatic Cylinders Manufacturer

We are a renowned manufacturer, exporter, supplier and trader of Hydro Pneumatic Cylinders. The offered pneumatic cylinders are utilized in different industries for their uninterrupted working system, reliable performance and premium quality. We offer the Hydro Pneumatic Cylinders based on the exact requirement of our esteemed clients. These cylinders are used for applications whee the job is automatically fed into the die and short travel is needed for pressing. The salient features of these tools include their easy maintenance system, long service life, well built construction and trouble free operational mode.

Specification of Hydro Pneumatic Cylinders

Type of Presses :	Capacity (Tone)	Stroke (mm)	Power Stroke (mm)
Hydro Pneumatic Cylinder	2,4,8,15,30	50,75,100,150	3,6,12,24
2 Piller Presses	2,4,8,15,30	50,75,100,150	3,6,12,24
4 Piller Presses	2,4,8,15,30	50,75,100,150	3,6,12,24
C Frame Presses	2,4,8,15,30	50,75,100,150	3,6,12,24
Compact C Frame Presses	2,4,8	50,75,100,150	3,6,12,24

Engineered for Versatility

Hydro Pneumatic Cylinders are designed with adaptability in mind. Whether you require a short stroke for compact operations or a long stroke for larger machinery, the cylinder can be tailored from 25 mm up to 1000 mm. Different mounting options, including flange, foot, and trunnion styles, provide seamless integration into your existing setup. These cylinders support both pneumatic and hydraulic operation, offering excellent force and speed for pressing, clamping, and forming tasks.

Reliable Performance in Harsh Conditions

Constructed with chrome-plated rods and available in aluminium or mild steel bodies, these cylinders excel in challenging environments. Enhanced surface treatments and optional stainless steel versions deliver strong corrosion resistance. Operating effectively between -10C and +80C, and with pressure ratings up to 200 bar hydraulic and 57 bar pneumatic, they maintain performance in a variety of industrial scenarios.

Low Maintenance, High Efficiency

Designed for longevity, the hydro pneumatic cylinders use high-quality PU and NBR seals to guarantee excellent leak-proof performance. The efficient double-acting structure ensures minimal air consumption while achieving high repeatability. With a low maintenance design, users benefit from reduced downtime and consistent, reliable operation in demanding production lines.

FAQs of Hydro Pneumatic Cylinders:

Q: How do hydro pneumatic cylinders differ from traditional pneumatic or hydraulic cylinders?

A: Hydro pneumatic cylinders uniquely combine the high force output of hydraulic systems with the precise control and quick response of pneumatic operation, offering both speed and power in one compact actuator.

Q: What is the customization process for stroke length and bore size in these cylinders?

A: Customers can specify their required stroke lengths (from 25 mm to 1000 mm) and bore sizes (32 mm to 400 mm). Our engineering team advises on the best sizing based on application parameters to ensure optimal performance and integration.

Q: Where are these cylinders typically used, and what are the key benefits?

A: These cylinders are commonly applied in pressing, clamping, riveting, punching, and forming operations across manufacturing industries. Their robust design delivers high output force and efficiency while reducing air consumption and maintenance needs.

Q: What materials and finishes are used for corrosion resistance in harsh environments?

A: The cylinders are constructed using aluminium or mild steel bodies with powder-coated or painted finishes, chrome-plated rods, and optional stainless steel components for maximum corrosion resistance, making them suitable for challenging operativo conditions.

Q: What control options are available for operating these cylinders?

A: Control can be manual or via solenoid valves, depending on the applications requirements, giving users flexibility over automation and operational precision.

Q: How is low maintenance achieved with these hydro pneumatic cylinders?

A: The low-maintenance design is achieved through high-quality PU and NBR seals for leak-proof operation, robust materials, and a simple double-acting structure, which collectively extend service life and reduce required interventions.
